The Ovation Hyperpower LX Series (Model: HP200LX-RE) is an ultra-budget, entry-level desktop power supply unit (PSU) widely sold in the Philippine market. It is engineered primarily for low-power office systems, data-entry terminals, or basic budget home computers that rely on integrated graphics.

⚙️ TECHNICAL SPECIFICATIONS

• Brand: Ovation

• Series Lineup: Hyperpower / LX Series

• Model Designation: HP200LX-RE

• True Rated Output: 200W (Continuous Power)

• Peak Power Support: 700W (Peak maximum burst capacity)

• AC Input Parameters: 180V – 240V AC ~ 5A, 50Hz (Standard domestic voltage profile for the Philippines)

• Form Factor: Standard ATX layout

🔌 CABLE & CONNECTOR CONFIGURATION

Because it is a 200W rated power supply, it features a minimalist, non-modular cable array meant to support core system components:

• 1 × 20+4 Pin Main Motherboard connector

• 1 × 4-Pin / P4 CPU Power connector

• 2 × SATA Power connectors (For modern 2.5" SSDs or 3.5" HDDs)

• 2 × IDE / Molex Peripheral connectors (For legacy drives or generic chassis fans)

• Note: It normally lacks a dedicated 6-pin or 8-pin PCIe cable because it is not intended to drive high-performance graphics cards.

❄️ COOLING & PROTECTION

• Cooling System: 1 × 120mm quiet-running exhaust fan located at the base of the metal chassis shroud.

• Safety Features: Standard fundamental electrical circuitry defense, including Short Circuit Protection (SCP), Over Voltage Protection (OVP), and Over Power Protection (OPP).

⚠️ IMPORTANT BUILDER'S ADVICE

This power supply is safely designed for specific, low-draw PC configurations. Understanding its limits is crucial to avoid hardware instability:

• What it is SAFE to run:

  • Office or online learning PCs running on processors with integrated graphics (e.g., AMD Ryzen 3 3200G, Ryzen 5 4600G/5600G, or Intel Core i3 / i5 setups without an added graphics card).

  • Basic system frameworks running single SSDs, standard office motherboards, and regular case fans.

• What it is NOT SAFE to run:

  • Do not use this power supply if you plan to install a dedicated gaming graphics card that requires external power connections (like an AMD RX 6600, RX 580, or NVIDIA RTX 3060/4060). Attempting to power a dedicated GPU on a 200W rated unit will cause system crashes, sudden shutdowns, or potential damage to your motherboard.
